Features |
|
|
| - |
Triple Output : DC~+30V/3A, DC~-30V/3A Dual / DC 5V/2A
Fixed |
| - |
Overload voltage and Ampere Protection
(SMPS) |
| - |
CC and CV Auto set |
| - |
Auto Tracking |
| - |
Key Lock to avoid error operation |
| - |
Setup : Setting and functions are selected
and stored in memory from the front panel. Eight setups
are stored in memory. |
| - |
Equipment : Display information about
your instrument including model number, serial number,
calibration date, GPIB address and firmware revision.
|
| - |
Remote Control : Built-in RS232C or
optional GPIB interface |
| - |
128 by 64 pixel super twisted LCD display
|
| - |
Power Source : 85V to 270VAC (กพ10%,
48 to 66Hz) |
 |
 |
 |
 |
| LCD Display |
Tracking Mode
|
Setup |
Equipment |
|
| |
Block Diagram |
|
|
| |
Specification |
|
|
|
|
| CHANNEL | 3 Channel (Two variable, One fixed) |
|
|
| Output Voltage |
|
Voltage |
|
| Current |
|
| 0 to +30V, 0 to -30V (Continuously variable)
Fixed 5V |
|
| Dual 0 กพ 3A, Fixed 2A |
|
|
|
| Resolution |
|
Voltage |
|
| Current |
|
|
|
|
| Operation
mode |
Constant Voltage (CV) |
| Constant Current (CC) |
|
|
| Ripple and Noise |
< 50mV rms |
|
|
| Load Regulation |
0.1% (at V = 15V, I = 1A) |
|
|
| Line Regulation |
< 1mV / V |
|
|
| Programming Accuracy |
0.5% of value กพ 3 digits |
|
|
| Read back Accuracy |
0.2% of value กพ 3 digits |
|
|
| General |
|
Power Source |
|
| Dimensions / Weight |
|
| Standard Accessories |
|
| Optional Accessories |
|
| 85V to 270Vac(กพ10%, 48 to 66Hz) |
|
| 235(W) x 296(D) x 85(H) mm / About 2.5 kg |
|
| Users Manual, Test Probe, Line Cord, Spare fuse,
RS232 Cable and S/W |
|
| GP-IB (IEEE-488.2) Interface (Installed) |
|
|
|
