Features |
|
|
| - |
P.A.M (Power Amplifier Modulation) Type /- CPU Control
(Digital Control) type |
| - |
I.G.B.T High Frequency Switch / - Low
Distortion Less than 1% |
| - |
Overload Protection based total power
concept / - Voltage Stability : ± 0.5% |
| - |
Frequency Stability: ±00.1% |
| |
APPLICATIONS |
|
|
| - |
Motor Testing / - Air Conditioner Testing / - Power
Supply testing |
| - |
General Laboratory / - Transformer Testing
/ - Magnetic Testing |
| - |
Reliability Testing / - Standard AC
SOURCE |
|
| |
Block Diagram |
|
|
| |
Specification |
|
|
| MODEL |
|
ACP-200 |
|
ACP-500 |
|
ACP-1K |
|
ACP-2K |
|
ACP-3K |
|
|
|
|
|
|
| Output Capacity |
200VA |
500VA |
1KVA |
2KVA |
3KVA |
|
|
Circuit Type
|
P.A.M (Power Amplifier Modulation) |
|
|
| Input Voltage |
100V / 110V / 115V / 120V / 200V / 230V / 240V / 380V
/ 440V, |
| 1PHASE or 3PHASE(Optional)
(±10%) |
|
|
| Input Frequency |
50㎐ / 60㎐ |
|
|
| Output Voltage |
0~300V (option : 0~700V),
1PHASE or 3PHASE(Optional) |
|
|
| Voltage Stability |
≤ ±0.5% |
|
|
| Output Frequency |
50,60,400,40~999㎐ (option :
10~5000㎐) |
|
|
| Frequency Stability |
≤ ±0.01% |
|
|
| T.H.D |
≤ 1% |
|
|
| Protector |
Electronic Circuit / Over Load / Short Circuit |
|
|
| Frequency Meter |
LED Digital Display Res 0.1㎐ |
|
|
| V.A-Meter |
True RMS LED Digital Display |
|
|
| Temperature |
0~40℃ |
|
|
| Humidity |
0~90% |
|
|
| Output Wave |
True sine Wave |
|
|
| * option |
Output Voltage : 0~700V or Higher |
|
|
| * option |
Output Frequency 20~3000㎐ |
|
|
| * option |
Output Metering Function |
|
|
| MODEL |
|
ACP-5K |
|
ACP-7.5K |
|
ACP-10K |
|
ACP-15K |
|
ACP-20K |
|
|
|
|
|
|
| Output Capacity |
5KVA |
7.5KVA |
10VA |
15VA |
20KVA |
|
|
Circuit Type
|
P.A.M (Power Amplifier Modulation) |
|
|
| Input Voltage |
100V / 110V / 115V / 120V / 200V / 230V / 240V / 380V
/ 440V, |
| 1PHASE or 3PHASE(Optional)
(±10%) |
|
|
| Input Frequency |
50㎐ / 60㎐ |
|
|
| Output Voltage |
0~300V (option : 0~700V),
1PHASE or 3PHASE(Optional) |
|
|
| Voltage Stability |
≤ ±0.5% |
|
|
| Output Frequency |
50,60,400,40~999㎐ (option :
10~5000㎐) |
|
|
| Frequency Stability |
≤ ±0.01% |
|
|
| T.H.D |
≤ 1% |
|
|
| Protector |
Electronic Circuit / Over Load / Short Circuit |
|
|
| Frequency Meter |
LED Digital Display Res 0.1㎐ |
|
|
| V.A-Meter |
True RMS LED Digital Display |
|
|
| Temperature |
0~40℃ |
|
|
| Humidity |
0~90% |
|
|
| Output Wave |
True sine Wave |
|
|
| * option |
Output Voltage : 0~700V or Higher |
|
|
| * option |
Output Frequency 20~3000㎐ |
|
|
| * option |
Output Metering Function |
|
|
|
|
