>MAIN 2-Channel DC Power Supply
PS-1303 / PS-1305


  Specification

Mode

PS-1303

PS-1305

Output Voltage

0-30V

0-30V

Output Current

0~3A

0~5A

Constant voltage operation

Line regulation

0.01%+3mV

Load regulation

0.01%+3mV

0.02%+5mV

Recovery time

50us(50~100% load change)

Ripple & Noise

1mV rms

Temperature co-efficient

300ppm/

Constant current operation

Line regulation

0.2%+3mA

Load regulation

0.2%+3mA

Ripple & Noise

3mA rms

Temperature co-efficient

500ppm/

Fixed Output

5V/1A

Voltage Accuracy

1%

Ripple & Noise

2mV rms

Display

Voltmeter display range

30V

Display resolution

100mV

Display accuracy

0.1%+2d

Ammeter display range

3A

5A

Display resolution

10mA

Display accuracy

0.1%+2d

Display mode

3 1/2 digit LED display

Power source

AC110V/220V, 50/60Hz

Operating environment

5~40, <80%

Storage environment

-10~70, <80%

Dimension

165w*130h*330dmm

Net Weight

Approx. 4.0kg

Approx. 5.6kg
